V110 – Marine Satellite Communication System
Installation Kit
Contains the items required for securing the antenna unit and ACU to
the vessel.
Antenna Size Q’ty Remark
Hex. Bolt M12x60L 5EA
Antenna-Deck
Hex Head
Wrench
Bolt
M6x40L 5EA
Dome
Washer
M6 5EA
Flat
Washer
M12 5EA
Spring
Washer
M12 5EA
Hex. Nut M12 10EA
ACU Size Q’ty Remark
Ta p p i n g
Screw
Ø4x16 5EA
Ta bl e M o u n t B r a c k e t-
Ta b l e
Flat Head
Screw
M3x8L 10EA
Rack Mount Bracket-
ACU
Sem’s
Bolt
M3x12L 5EA
Ta b l e M o u n t B r a c k e t-
ACU
Figure 4. Installation Kit Components
