Intellian V110 User Manual

7
Other Components
Item Image Description Size Q’ty Remark
1
ACU
Bracket
Rack - 2EA ACU-19inch Rack
Table - 2EA ACU-Table
2 RG6 Cable 3m 1EA
ACU(MODEM RX) to
Modem
3 RG6 Cable 15m 2EA
Antenna(MODEM IN)
to Modem &
Antenna(ACU RX)
to ACU(ANT RX)
4.
BUC Power
Cable
15m 1EA
Antenna (BUC IN) to
ACU (BUC POWER)
5
AC Power Cord
( CEE7/7)
1.5m 1EA ACU Power
6 PC Serial Cable 1.8m 1EA ACU to PC
7.
USB Cable
(A-A / M-M)
1.8m 1EA ACU to PC
8.
iDirect
Interface Cable
1.5m 1EA ACU to Modem
9.
D-Sub
9 Pin Male
Connector
2EA ACU
10
Gyro NMEA /
BUC Power
Connector
AK950-2 3EA
ACU(Gyro NMEA /
BUC Power ) &
Antenna (BUC IN)
11
Install CD
- 1EA -
Installing the Antenna
