V110 – Marine Satellite Communication System
Antenna Dimension
The method of installation and mounting of antenna may vary with
vessel design but the following procedures are applicable in most
situations, and will result in a secure and effective installation. Confirm
the height and diameter the antenna before installing it.
Ø146.8cm
(57.8”)
151.7cm
(59.7”)
Figure 12. Radome Dimension
