21
M12 Hex. Bolt
Antenna Unit
Deck
M12 Flat Washer
M12 Spring Washer
M12 Hex. Nut
19mm Spanner
Radome Hatch
Figure 16. Open Radome Hatch before Removing Web Strap
Mounting the Radome
Bolt the Radome base directly to the ship’s deck or mounting plate (flat
mounting area).
Figure 17. Mounting the Radome Diagram
WARNING: The elevation and cross-level motor breaks prevent dish
damage while the antenna is in power off mode. However,
Intellian strongly recommends to restraint the antenna pedestal
properly during underway conditions when power is removed
from the antenna. The normal operating condition for the v110
is to remain powered up at all times.
Installing the Antenna
To Next Page
