Intellian V110 User Manual

44
V110 – Marine Satellite Communication System
BOW ADJUST EL.ADJUST
▲ 0
00 ▼ +0.0
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
7. Set BOW ADJUST and EL. ADJUST
The bow adjust is to offset the angle difference between the antenna’s bow and the
ship’s bow (Range :0 – 360°) and the elevation adjust is to offset the angle difference
between the mechanical elevation angle and actual elevation angle (Range : ± 5°).
Press LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Press UP and DOWN arrow keys to increase and decrease the selected character. Or
press NUMBER keys to set the desired value directly. Press OK key to set the
parameter. Press RETURN key to select the parameter you wish to edit and press the
RETURN key again to save or abort and return to the main display.
OK
M
R
F
BOW AUTO SAVE EXT.LOCK ACTIVE
▲ YES ▼ LOW
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Cont rol Unit
8. Set BOW AUTO SAVE and EXT. LOCK ACTIVE
The bow auto save is to save BOW information automatically. This function will be
activated when the antenna finds peak position.
Ext. lock active here is referred that modem lock output from the modem provides a logic
input via a voltage to the ACU to identify when it is on the correct satellite. This setting
can be varied from modem to modem. (Refer to the modem manual for details.)
Press UP and DOWN arrow keys to select the parameter options. Press OK key to set
the parameter. Press RETURN key to select the parameter you wish to edit and press
RETURN key again to save or abort and return to the main display.
OK
M
R
F
