Intellinet 525688 - Hardware Installation; III-1. Connecting the Access Point to a Router or Poe Switch

11

III. HardwareInstallation

III‐1. ConnectingtheaccesspointtoarouterorPoEswitch
1.  Ifyouneedto,removethecapfromtheundersideoftheaccesspoint.
Thiscreatesextraspaceforyourcablestopassthrough.


2.  ConnectarouterorPoEswitchtotheaccesspoint’sLANportusingan
Ethernetcable.

3.  Ifyouareusingarouter,connectthe
poweradaptertotheaccesspoint’s
12VDCportandplugthepower
adapterintoapowersupply.

Donotusethepoweradapterif
youareusingaPoEswitch.
