IV‐2‐3. VLAN
TheVLAN(VirtualLocalAreaNetwork)screenenablesyoutoconfigureVLAN
settings.AVLANisalocalareanetworkwhichmapsworkstationsvirtually
insteadofphysicallyandallowsyoutogrouptogetherorisolateusersfrom
eachother.VLANIDs1–4094aresupported.

VLANIDsintherange1–4094aresupported.



VLANInterface
WiredLAN
Port/Wireless
IdentifiesLANport1and wirelessSSIDs
(2.4GHzor5GHz).
VLANMode Select“TaggedPort”or“UntaggedPort”for a
LAN interface.
VLANID SetaVLANIDforaspecifiedinterface,if
“Untagged Port”isselected.

ManagementVLAN
VLANID SpecifytheVLANIDofthemanagementVLAN.
OnlythehostsbelongingtothesameVLANcan
managethedevice.


 
