Intellinet 525688 - IV-1-3. Wireless Monitor

24

2.4GHz(5GHz)WLANClientTable
SSID DisplaystheSSIDwhichtheclientis
connectedto.
MACAddress DisplaystheMACaddressoftheclient.
Tx Displaysthetotaldatapacketstransmittedby
thespecifiedclient.
Rx Displaysthetotaldatapacketsreceivedby
thespecifiedclient.
Signal(%) Displaysthewirelesssignalstrengthforthe
specifiedclient.
ConnectedTime Displaysthetotaltimethewirelessclienthas
beenconnectedtotheaccess point.
IdleTime Clientidletimeisthetimeduringwhichthe
clienthasnottransmittedanydatapackets;
i.e.,hasbeen idle.
Vendor Thevendoroftheclient’swirelessadapteris
displayedhere.

IV‐1‐3. WirelessMonitor
WirelessMonitorisatoolbuiltintotheaccesspointtoscanandmonitorthe
surroundingwirelessenvironment.Selectafrequencyandclick“Scan”to
displayalistofallSSIDswithinrangealongwithrelevantdetailsforeachSSID.


