III‐3. T‐RailMount
TomounttheaccesspointtoaT‐rail,followtheinstructionsbelowandrefer
todiagramC,D&E.

1.  SelectthecorrectsizeT‐railbracketfromthetwosizesincludedinthe
package.

2.  AttachtheT‐railbracketitoholeiiusingscrewiii(x2)asshowninC.

IfyouneedmorespacebetweentheaccesspointandtheT‐rail,
usebracketivbetweenbracketiandholeii(x2),andusethe
longerscrews(x2)included inthepackage.

3.  CliptheaccesspointontoyourT‐railusingthenowattachedT‐rail
bracket.

C
