21


System
Model Displaysthemodelnumberoftheaccess
point.
ProductName Displaystheproductnameforreference,
whichconsistsof“AP”plustheMACaddress.
Uptime Displaysthetotaltimesincethedevicewas
turnedon.
BootFrom Displaysinformationforthebooted
hardware.
Version Displays the firmware version.
MACAddress Displays the accesspoint’sMACaddress.
ManagementVLAN
ID
DisplaysthemanagementVLANID.
IPAddress DisplaystheIPaddressofthisdevice.Click
“Refresh”toupdatethisvalue.
Default
Gateway
DisplaystheIPaddressofthedefault
gateway.
DNS IPaddressofDNS(DomainNameServer).
DHCPServer IPaddressofDHCPServer.

WiredLANPortSettings
WiredLANPort SpecifieswhichLANpor t.
Status DisplaysthestatusoftheLANport(connected
ordisconnected).
VLANMode/ID DisplaystheVLANmode(taggedoruntagged)
andVLANIDfortheLANport.SeeIV‐2‐3.
VLAN

Wireless2.4GHz(5GHz)
Status Displaysthestatusofthe2.4GHzor5GHz
wireless(enabledordisabled).
MACAddress Displays the accesspoint’sMACaddress.
Channel Displaysthechannelnumberthespecified
wirelessfrequencyisusingforbroadcast.
TransmitPower Displaysthewirelessradiotransmitpower
levelasapercentage.



