43

2.4GHz
WDSFunctionality Select“WDSwithAP”touseWDSwithan
accesspointor“DedicatedWDS”touseWDS
andalsoblockcommunicationwithregular
wirelessclients.WhenWDSisused,each
accesspointshouldbeconfiguredwith
correspondingMACaddresses,wireless
channelandwirelessencryptionmethod.
LocalMACAddress DisplaystheMACaddress ofyouraccesspoint.

WDSPeerSettings
WDS# EntertheMACaddressforuptofourother
WDS devicesyouwishtoconnectto.

WDSVLAN
VLANMode SpecifytheWDSVLANmode to“Untagged
Port” or“TaggedPort.”
VLANID SpecifytheWDSVLANID when“Untagged
Port”isselectedabove.

WDSEncryptionmethod
Encryption Selectwhethertouse“None”or“AES”
encryptionandenterapre‐sharedkeyforAES
consistingof 8‐63alphanumericcharacters.


