Intellinet 525800 - Technical Specifications

High-Power Ceiling Mount Wireless 300N PoE Access Point
56
TechnicalSpecifications
Specification
ROM RAM 4/8/16M DDR1:16/32/64M
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE
802.3u,IEEE802.3af 
InterfaceType
1‐Port 10/100 RJ45 Ethernet interface, support the 802.3af
standard
RFPower
11b:27dbm（max）
11g:24dbm（max）
11n:23dbm（max）
RadioDataRate
11n:Upto300Mbps
11g:54/48/36/24/18/12/9/6M
11b:11/5.5/2/1M
Sensitivity@PER
11N_MCS7_20M:‐70dBm@10%PER;
11N_MCS7_40M:‐69dBm@10%PER;
54M:‐72dBm@10%PER;
11M:‐88dBm@8%PER;
security WEP,WPA2/WPA‐PSK(AES,TKIP)
Frequencyrange 2.4~2.4835GHz
Antennas
2PCS2.4GOmnidirectional2dBiThebuilt‐inantenna2dBifixed
Antennas
Max.Consumption 9W(Max)
Dimensions(DxH) (144*42.5)mm
Environment
OperatingTemperature:‐0Ԩ‐40Ԩ
StorageTemperature:‐40Ԩ‐70Ԩ
OperatingHumidity:10%‐90%RHnon‐condensing
Storagehumidity:5%‐95%RHnon‐condensing



