Interacoustics AA222 User Manual

AA222 Instructions for Use – US Page 82
5.3 Pin Assignments
Socket
Connector
Pin 1
Pin 2
Pin 3
IN 24V DC / 2.5A
Ground 24V in -
Left & Right
6.3mm Mono
Ground Signal
-
Bone
Contra
Pat. Resp.
TB
6.3mm Stereo
Ground DC bias Signal
Assist Mon.
3.5mm Stereo
Ground
Right
Left
TF
Ground
DC bias
Signal
CD
Ground CD2 CD1
FF1 & FF2
Ground Signal -
USB A
USB B (Device)
1. +5 VDC
1. +5 VDC
2. Data -
2. Data -
3. Data +
3. Data +
4. Ground
4. Ground
LAN
RJ45 Socket
RJ45 Cable Plug
1. TX+ Transmit Data+
1. TX- Transmit Data-
2. RX+ Receive Data+
3. Not connected
4. Not connected
5. RX- Receive Data-
6. Not connected
7. Not connected
