Interlogix xGen Lite

xGen Lite Installation and Programming Guide 3
Product
Description
EN grade
NXG-1820
3.5 inch Touchscreen keypad, multilingual
2/3
NXG-208-G3
8 zone expander
2/3
NXG-220-G3
20 zone expander
2/3
NXG-504
4 relay output expander
2/3
NXG-510
10 relay output expander
2/3
NXG-001
Plastic housing /w tamper switch
2
NXG-005
Pry-off tamper switch incl metal U-bracket
2/3
NXG-003
Housing /w tamper sw - Metal EN Grade 2
2
NXG-003-DIN
DIN-rail mounting kit
2/3
NXG-868
Wireless expander 868 MHz Gen 2
2
NXG-433
Wireless expander 433 MHz
2
NXG-7002(-SIM)
4G/wifi communication expander (- SIM includes SIM card)
2
Mains Power Specifications
Mains input voltage
230 VAC +10%, −15%, 50 Hz ±10%
Current consumption at 230 VAC
240 mA max.
Transformer output:
NXG-4
16.3 VAC 35 VA
NXG-8
16.3 VAC 40 VA
NXG-9
16.3 VAC 40 VA
Installation Instructions for Service Persons
An appropriate disconnect device, to control the mains power to this device, is to
be provided as part of building installation according to the local wiring rules.
Power Supply Specifications
Power supply type
EN 50131-6 Type A for indoor use
inside the supervised premises
Power supply voltage
13.8 VDC ± 0.4 V
Power supply current
2 A max. at 13.8 VDC ± 0.4 V
Main board consumption:
xGenLite
130 mA at 13.8 VDC ± 0.4 V
Maximum system current available:
xGenLite
2000 mA at 13.8 VDC ± 0.4 V
Auxiliary power output (AUX. POWER):
xGenLite
13.8 VDC ± 0.4 V, 1 A max.
