4 xGen Lite Installation and Programming Guide
Battery power output (BAT):
NXG-4
13.8 VDC ± 0.2 V, 350 mA max.
NXG-8
13.8 VDC ± 0.2 V, 350 mA max.
NXG-9
13.8 VDC ± 0.2 V, 570 mA max.
Battery type
Lead acid rechargeable
BS127N: 7.2 Ah 12 V nominal
BS130N: 12 Ah 12 V nominal
BS131N: 18 Ah 12 V nominal (NXG-8
only)
Note: Use of the second battery is not
compliant for EN installations.
Minimum voltage
9.45 VDC
Over-voltage threshold
16.3 VDC ± 5%
Maximum voltage at power supply, auxiliary power
output and battery power output
14.5 VDC
Battery low condition
11.3 to 11.8 VDC
Battery disconnect voltage
9.77 VDC
Maximum ripple voltage V, p-p
200 mV typical, 400 mV max.
General Features
Code combinations:
xGenLite
From 10,000 (4 digits) to 100,000,000 (8 digits)
Maximum user number:
NXG-4
40
NXG-8, NXG-9
100
User Permissions:
NXG-4
32
NXG-8, NXG-9
64
Onboard zones:
NXG-4
4 (default); 8 if zone doubling enabled.
NXG-8, NXG-9
8 (default); 16 if zone doubling enabled.
Maximum zone number:
NXG-4
16
NXG-8, NXG-9
48
Additional inputs:
NXG-4, NXG-8
1: box tamper
NXG-9
2: box tampers
End-of-line resistor
820 Ω (2-wire smoke)
3.3 kΩ, 4.1 kΩ, 4.7 kΩ (alarm)
3.74 kΩ, 6.98 kΩ (zone doubling)
