110 xGen Installation & Programming Guide
Actions can be used without programming an Action Result. For example,
outputs on xGen are controlled by monitoring an Action State, no Action Result
needs to be programmed.
Menu Overview
Instructions
1. Open Actions
2. Select the Action Number you want to create
3. Enter a descriptive name for this action
4. Select the Action Function and the duration (optional) for the Action State.
For example, Timed 5 seconds would cause the Action State to activate for 5
seconds when all the conditions in the Event Equation are satisfied.
5. Select the Event 1 logic, this will be applied before Event 1.
For example, “Inverted OR” results in “NOT Event 1”
6. Program the first event by using the Category and Type menus
8. Actions 19. Action Groups
Events to be
monitored
To Next Page
