100 xGen Installation & Programming Guide
Programming Instructions for Channels
Goal
Set up communication paths and destinations for delivering event messages.
Pre-conditions
1. Communicator must be programmed (see Communicator Programming).
2. Event Lists must be programmed (see Event Programming).
Notes:
Partition Account Number will take priority over Account Number entered here for
Zone events. If no Partition Account Number is entered then this number will be
used instead.
Next Channel must be a higher value than the current Channel Number. Circular
loops are not permitted.
Take note of the Sequence Attempts under Communicator – System Event
Reporting (6.11.2). This is the number of times xGen will attempt the sequence of
Channels you set up in this section.
Channel Group 1
Channel 1
Channel 2
Channel 3
Event List 1
Critical
Event
Menu 6.11.1.1 or 4
Channel Group 1
System / Partition
Channel 2
Control Room 2
Event List = 1
Channel 3
Email
Event List = 2
Channel 1
Control Room 1
Event List = 1
Menu 18 – Channel Groups
Event sent t
o
Channel Group
Channel Group sends event
to every Channel it contains
Menu 5 – Channels
Each channel checks to
see if the event is on its
Event List, if yes it will
attempt to send, if not
then it stops.
Menu 17 – Event Lists
Event List 2
Informational
Open & Closes
Autotest
Alarms
Bypass & Restore
AC Fail
