Page #17 background image
EasyLAN Wireless Interface Kit Installation Instructions 13
2
Physical Installation
is chapter describes how to physically install the
EasyLAN Wireless interface kit in a PF2/4i-, PM4i-,
or PX4/6i-series printer.
e installation described in this chapter
must only be performed by an authorized
service technician. Intermec assumes
no responsibility for personal injury or
damage to the equipment if the instal-
lation in performed by an unauthorized
person.
Take precautions against electrostatic
discharges, for example by wearing
grounded bracelets.
Note: When the EasyLAN Wireless
interface is factory-installed in a printer,
the antenna is packed separately in the box
and must be fi tted to its connector on the
printers rear plate as illustrated at the end
of this chapter.

Other manuals for Intermec EasyCoder PF4i

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intermec EasyCoder PF4i and is the answer not in the manual?

Intermec EasyCoder PF4i Specifications

General IconGeneral
Print technologyDirect thermal
Maximum resolution203 x 203 DPI
Standard interfacesRS-232, USB 2.0
Internal memory16 MB
Power consumption (standby)15 W
Power consumption (printing)300 W
Media thickness3/7.5 mm
Maximum label width104 mm
Maximum label length0.4 m
Maximum roll diameter152.4 /213 mm
Maximum internal memory1 GB
Supported network protocolsTCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product colorBlue, Silver
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)40 - 104 °F
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth405 mm
Width244 mm
Height178 mm
Weight8000 g
