Intermec EasyCoder PF4i Installation Instructions

2 EasyLAN Wireless Interface Kit Installation Instructions
Chapter 1 — Introduction
About These Instructions
 ese instructions describe how to install an EasyLAN Wireless network
interface in an EasyCoder PF2i, PF4i, PF4i Compact Industrial, PM4i,
PX4i, or PX6i printer and how to connect it to a LAN, WAN, Intranet,
or Internet network via a wireless connection.
 e installation instructions describe how to physically install the inter-
face board in a printer and how to set up the IP address, subnet mask,
default router, and name server.  e instructions end when you have
the printer’s home page up and running. From there, please refer to the
Intermec EasyLAN User’s Guide on the included CD-ROM.
 is interface kit must only be physically installed by an
authorized service technician.  e device is country/region
specifi c and must be ordered for the correct country/region.
Use of this device in other region than shown on the device
home page/test label may violate applicable law.
Printer Firmware
For full functionality, your printer should either be fi tted with Intermec
Fingerprint v8.40 (or later) or IPL v2.40 (or later). In Intermec Finger-
print, the network port is addressed as device "net1:" (communication
channel #5).
Installation Kit
 e EasyLAN Interface Kit contains:
• One EasyLAN adapter board complete with radio module fi tted
• Rear plate (for EasyCoder PF2/4i-series printers only)
• RJ-45 plug (for EasyCoder PM4i and PX4/6i only)
• One light guide
• One hexagonal threaded spacer
• One antenna extension cable
• One antenna
• One cable clip
• One cable tie
• One CD-ROM with software and manuals
•  is Installation Instruction booklet
 e only tools required for the installation are #T10 and #T20 Torx

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
