Intermec EasyCoder PF4i Installation Instructions

EasyLAN Wireless Interface Kit Installation Instructions 37
Chapter 4 — Setup in Fingerprint
An additional item is “STATE”, which is read-only for all users:
SETUP GET "8021x","STATE",A$
Gets the supplicant state: “Disabled”, “Failed”, “Authenticating”, or
“Authenticated”.
Note: If you start the printer with EAP type set to OFF and
then change the EAP type to TTLS, LEAP, or PEAP, you need
to reboot the printer for your new settings to take eff ect. Until
you reboot, STATE returns “Disabled.”
802.1x supplicant state, EAP type, outer name, inner authentication,
installed root certifi cate, server common names, and server certifi cate
validation can be seen on the printer's web page and the network test
label.
Reading Other Wireless Connection Variables
In addition to SSID, WEP, WLAN, and 802.1x settings, the following
information can be read using SETUP GET instructions:
• Active channel
1,3
• MAC address of the access point
1
• Signal strength
1,3
• Speed
1
• Region
2
1
/.  e information is also given on the network test label and on the
web page.
2
/.  e current region is also presented on the web page.
3
/. Active channel and signal strength is shown in the printer’s display
window when the <i> key is pressed.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
