EasyLAN Wireless Interface Kit Installation Instructions 21
Chapter 2 — Physical Installation
Antenna
EasyCoder PM4i printer
EasyLAN adapter
board
Light guide
Cable clips
#T20 Torx screw
and spacer
Antenna
cable
Cable tie
EasyCoder PM4i printer, rear view
Antenna
(packed separately
when the EasyLAN
Wireless interface is
factory-installed)
