DriveControl DC-20/DC-54
Assembly
Warning notices concerning assembly
 Do not drop or mishandle the DriveControl to avoid internal damage.
 Check each DriveControl visually for damage before assembly.
Warning notices concerning the electrical installation
 Electrical work should only be performed by qualified and authorized persons.
 Disconnect the power supply before installing, removing or rewiring the
DriveControl.
 Ensure that no hazardous voltage can come into contact with the connections
or the housing, not even in the event of a malfunction or fault.
 Do not connect AC current to the RollerDrive or the DriveControl at any time,
as this will cause irreparable damage to the device.
 Do not use earth connections or earth wires as a protective conductor (PE).
 Do not apply too much tension or load to the motor plug. The cable insulation
can become damaged if the cable is bent at the plug and the DriveControl or
the RollerDrive could fail.
 Ensure that existing electrical installations do not interfere with the
DriveControl or the RollerDrive.
 Only use cables that are dimensioned sufficiently for the application.
 Ensure that current load at each terminal or terminal block does not exceed
10 A.
 Ensure that the switching power supply unit supplying the DriveControl
supplies a nominal DC voltage of 24 V with a maximum deviation of ±8 %.
 Ensure that the RollerDrive, the DriveControl and the voltage source are
connected to the conveyor frame or supporting structure in such a way that
they are properly earthed. Incorrect earthing can result in the build-up of static
charge, causing the motor or DriveControl to malfunction or fail prematurely.
 Only use the specified mating plug (see "Inputs and outputs", page 18) and
the spare tool supplied.
 Only apply operating voltage when all of the cables have been connected.
Risk of damage leading to failure or shortened life
expectancy of the DriveControl
 Follow the instructions below.
Risk of damage to the DriveControl
 Observe the following safety information.
