DriveControl DC-20/DC-54
Appendix
Electrical data of connectors
Inputs/outputs connectors Input 24 V (pin 2)
Output ERROR (pin 3)
Inputs SPEED A, SPEED B, SPEED C and DIR (pin 4 - 7)
Properties electrically isolated
Dielectric strength max. 500 V
eff
1 min, 50 Hz
Reverse polarity
protection
max. 30 V DC
Current consumption max. 50 mA must be ensured via external
circuit
Properties electrically isolated, infeed of external voltage not
permitted
Dielectric strength max. 500 V
eff
1 min, 50 Hz
Logic level with error max. 1 V DC external load resistance required
to GND
Output current with
error
max. 0.1 mA
Logic level with no error 10 to 25 V DC
Output current with no
error
max. 50 mA not short circuit-proof
Impedance related
toCOMMON GND
4.7kΩ
Hint
The error signal can be linked by connecting the output error of a previous
DriveControl with the 24 V input of a subsequent DriveControl. The logic level
with "no error" is hereby reduced by 1.1 V per DriveControl.
Properties debounced, electrically isolated
Reverse polarity
protection
max. 30 V DC
Overvoltage protection max. 30 V DC permanent, absence of harmonic
waves
Dielectric strength max. 500 V
eff
1 min, 50 Hz
Logic level low 0 to 1 V DC logical 0 = L = inactive
Input current low max. 0.1 mA
Logic level high 18 to 26 V DC logical 1 = H = active
Input current high 2.5 to4.5 mA
