Interroll DriveControl 20 - Operation

24
Version 2.0 (11/2013) en
Translation of the original instructions
DriveControl DC-20/DC-54
Initial startup and operation
Operation
Internal speed setting on the
DriveControl
Requirement: The external inputs SPEED A, B, C are logically inactive.
 Set the required speed using the DIP switches (see table).
 Switch one of the inputs SPEED A, B, C to logical active to start the
RollerDrive.
The RollerDrive rotates with the set speed.
 To stop the RollerDrive, switch all inputs SPEED A, B, C to logical inactive.
Accidental start-up of the RollerDrive
Danger of crushing of limbs and damage to goods
 Ensure that no unauthorized persons are near the
conveyor before switching on the operating voltage.
CAUTION
Hint
Ambient conditions during operation see "Technical Data", page 11
Setting of the SPEED DIP switches
on the DriveControl
Speed at gear ratio
m/s
ABCD9:112:116:120:124:136:148:164:196:1
on on on on 1.75 1.31 0.98 0.78 0.65 0.44 0.33 0.25 0.16
on on on off 1.63 1.22 0.92 0.73 0.61 0.41 0.31 0.23 0.15
on on off on 1.51 1.13 0.85 0.68 0.57 0.38 0.28 0.21 0.14
on on off off 1.39 1.04 0.78 0.62 0.52 0.35 0.26 0.20 0.13
on off on on 1.27 0.95 0.72 0.57 0.48 0.32 0.24 0.18 0.12
on off on off 1.15 0.86 0.65 0.52 0.43 0.29 0.22 0.16 0.11
on off off on 1.03 0.78 0.58 0.47 0.39 0.26 0.19 0.15 0.10
on off off off 0.92 0.69 0.52 0.41 0.34 0.23 0.17 0.13 0.09
off on on on 0.80 0.60 0.45 0.36 0.30 0.20 0.15 0.11 0.07
off on on off 0.68 0.51 0.38 0.31 0.25 0.17 0.13 0.10 0.06
off on off on 0.56 0.42 0.32 0.25 0.21 0.14 0.11 0.08 0.05
off on off off 0.44 0.33 0.25 0.19 0.17 0.11 0.08 0.06 0.04
off off on on 0.32 0.24 0.18 0.15 0.12 0.08 0.06 0.05 0.03
off off on off 0.21 0.15 0.12 0.09 0.08 0.05 0.04 0.03 0.02
off off off on 0.09 0.07 0.05 0.04 0.03 0.02 0.02 0.01 0.01
off off off off Corresponding to the signals at the inputs SPEED A, B, C
