DriveControl DC-20/DC-54
Initial startup and operation
External speed setting via
digital inputs
Requirement: All DIP switches SPEED A, B, C, D are switched to OFF.
 Switch the external inputs SPEED A, B, C to logically active or inactive
according to the table below to start the RollerDrive with the required speed.
 To modify the speed, correspondingly modify the signals at the inputs SPEED
A, B, C.
 To stop the RollerDrive, switch all inputs SPEED A, B, C to logical inactive.
* H = logically active; L = logically inactive
Hint
The internal speed setting has priority. If during external speed setting one or
several internal DIP switches are switched from SPEED A, B, C, D to ON, the
RollerDrive rotates with this internally set speed, independent of signals from the
external inputs. When all internal DIP switches SPEED A, B, C, D are set to OFF,
the RollerDrive rotates again with the speed set via the external inputs.
inputs SPEED at the DriveControl * Speed at gear ratio
m/s
ABC9:112:116:120:124:136:148:164:196:1
HHH1.751.310.980.780.650.440.330.250.16
H H L 1.47 1.10 0.83 0.66 0.55 0.37 0.28 0.21 0.14
H L H 1.19 0.89 0.67 0.53 0.45 0.30 0.22 0.17 0.11
H L L 0.92 0.69 0.52 0.41 0.34 0.23 0.17 0.13 0.09
L H H 0.64 0.48 0.36 0.29 0.24 0.16 0.12 0.09 0.06
L H L 0.36 0.27 0.20 0.17 0.14 0.09 0.07 0.05 0.03
L L H 0.09 0.07 0.05 0.04 0.03 0.02 0.02 0.01 0.01
L L L 000000000
inputs SPEED at the DriveControl * Speed at gear ratio
ft/min
ABC9:112:116:120:124:136:148:164:196:1
HHH34425819315412887654931
H H L 289 217 163 130 108 73 55 41 28
H L H 2341751321048959433322
H L L 181 136 102 81 67 45 33 26 18
L H H 126 94 71 57 47 31 24 18 12
L H L 71533933281814106
L L H 181410864422
L L L 000000000
