FUNDAMENTALS
8
Layout - Charging Device
LED
GLOW
RING
Top View With
Terminal Cover
interVOLT Model
DCC1225ACD
Battery to Battery
Charging Device
12VDC - 12VDC
25 Amps max.
COMMON
NEGATIVE
TERMINAL
REMOTE
DISPLAY
OUTPUT
IGNITION
CONTROL
TERMINAL
MOUNTING
FEET
SOLAR
PANEL
POSITIVE
TERMINAL
MAIN
BATTERY
POSITIVE
TERMINAL
AUXILIARY
BATTERY
POSITIVE
TERMINAL
Top View Without
Terminal Cover
Note: Images above shown approximately half actual size.
