SPECIFICATIONS
34
Input Voltage
Main
Solar
9 – 17 VDC
27 VOC max. (open circuit – no load)
Solar Power 250 Watts nominal (300 Watts peak)
Continuous Rating 25 Amps @ 50°C
Current Draw
Charging Device
Remote Display
Including LED indicator <10mA (in standby)
With backlight off: 10mA max
With backlight on: 30mA max
Boost Voltage
Standard Lead Acid
Absorbed Glass Mat
Gelified Electrolyte
Lead Calcium
14.4 VDC Nominal
14.6 VDC Nominal
14.2 VDC Nominal
14.8 VDC Nominal
Float Voltage 13.2 VDC Nominal
Electrical Protection Thermal overload shutdown – auto reset
Electrical overload shutdown – auto reset
Under voltage disconnect – auto re-connect
Over voltage disconnect – auto re-connect
Reverse polarity protection of main terminals
Environmental Protection
Charging Device
Remote Display
IP67 (internal components only)
IP40 (not dust or water resistant)
Operating Temperature -20°C to +85°C
Operating Humidity Up to 98%
Charging Device Materials
Heatsink
Blue Plastics
Black Plastics
Transparent Plastics
E-Coated ADC-3 die cast aluminium
Temperature resistant PC/ABS alloy
15% glass reinforced PBT
Temperature resistant PMMA
Remote Display Materials
Dark Grey Plastics
Transparent Plastics
Temperature resistant PC/ABS alloy
Temperature resistant PMMA
Terminal Material Tin plated brass
Terminal Fasteners 304 stainless steel
Conformity AS/NZS CISPR 11:2004 for EMC
Dimensions
Charging Device
Remote Display
112 x 112 x 75mm (including terminal cover)
60 x 36 x 59mm (including mounting bracket)
Weight
Charging Device
Remote Display
690 grams
55 grams
