OPERATION
31
System Status
The DCC Pro has a number of protection and monitoring mechanisms built in
to protect the product from application and installation issues as well as faults
that may occur in exceptional circumstances. To assist with troubleshooting any
problems that arise, the DCC Pro can indicate these issues in one of two ways,
via the Charging Device itself or on the Remote Display (if connected).
The Charging Device incorporates the LED Glow Ring, a multi-colour,
multi-function indicator which is illuminated according to the status of the
device. The Glow Ring will reect a range of conditions as a visual indication to
the operator/installer.
The Remote Display can visually and audibly alert the operator to the same
conditions as indicated by the LED Glow Ring with the advantage, as the name
indicates, of being located away from the Charging Device. These conditions
are detailed in the table below.
Glow Ring
Colour
Glow Ring
Frequency
Status
Remote Display
Indication
Condition
Charger
State
White
Intermittent
(8 seconds)
Standby
STAND BY*
Normal
Aqua
Green
Continuous
Primary
Solar
PRM SOLAR
Normal On
Aqua
Green
Intermittent Silent Solar
SLT SOLAR*
Normal On
Purple Intermittent Set-up
TO CONFIG...
Normal
Blue Continuous Boost
BOOST
Normal On
Blue/Green Alternate Absorption
ABSPN
Normal On
Green Continuous Float
FLOAT
Normal On
Red Intermittent
General
Fault
CHRGR OFF
Alert¹
Yellow Intermittent Low Voltage
BAT FAULT
Alert²
Orange Intermittent
High
Temperature
OVERTEMP
Alert
3
O
O
O
O
O
*Use the button to ‘awaken’ the display for temporary viewing.
NOTE: For further information on alert conditions please refer to troubleshooting
guide on following pages.
