Assembly Instructions
1-150-068-A CS Bed Manual.doc © Carroll Healthcare Inc. Page 17 of 35
76” Bed ONLY
Remove the fasteners on the bed end
bracket
76” Bed ONLY
Slide the bed end bracket in the
mounting channel. Align the hole in
the bracket with the channel hole.
76” Bed ONLY
Reinsert the bed end bracket fasteners
76” Bed ONLY
Tighten the fasteners with two 7/16
wrenches. Reposition the other three
brackets and reapply the ends.
Position the mattress on the deck. Press the mattress inside the mattress
keeper. Ensure the mattress is engaged
on all four corners.
