Product Specifications
1-150-068-A CS Bed Manual.doc © Carroll Healthcare Inc. Page 7 of 35
TECHNICAL SPECIFICATIONS - CARROLL CS SERIES BED
CS7 CS9
Certifications
Canada CSA C22.2 No. 601.1 CSA C22.2 No. 601.1
USA UL Std. 60601-2-38 UL Std. 60601-2-38
Elevation Range (floor to deck)
Stability Range (off casters) 7" to 30" (178 to 762 mm) 9" to 30" (229 to 762 mm)
Mobility Range (on Casters) 7" to 30" (178 to 762 mm) 9" to 30" (229 to 762 mm)
Head Deck Angle 0° to 70° 0° to 70°
Knee - Foot Angle 0° to 30° 0° to 30°
Under-bed clearance for 2/3 of bed - centered 14” (356 mm) 14” (356 mm)
Electrical Specifications
Control Box Mains Voltage 120V~ 120V~
Control Box Input Current 3.5A max 3.5A max
Control Box Current Frequency 60 Hz 60 Hz
Control Box Output Voltage 24 Volts DC (70W max) 24 Volts DC (70W max)
Control Box Duty Cycle 10% Max (2 min ON 18 min OFF) 10% Max (2 min ON 18 min OFF)
Motorised Linear Head Actuator 24 Volts DC 24 Volts DC
Motorised Linear HILO Actuator (head end
mount)
24 Volts DC 24 Volts DC
Motorised Linear HILO Actuator (foot end
mount)
24 Volts DC 24 Volts DC
Motorised Linear Foot Actuator 24 Volts DC 24 Volts DC
Eight button hand pendant with contour function standard standard
Safety Features
Protective Earth Ground Class I Class I
Electric shock protection Type B Type B
Enclosure protection IPX4 IPX4
Floor Lock standard standard
Quick Release CPR Handle optional optional
Built-in Battery Back-up optional (24V DC 9.2 Amps) optional (24V DC 9.2 Amps)
Portable Battery Back-up optional (24V DC 9.2 Amps) optional (24V DC 9.2 Amps)
Security - Pendant Lock-Out
Pendant Disconnection standard standard
ACL (Attendant Control Lockout) Pendant HILO
Function Lock-Out
optional optional
ACP (Attendant Control Panel) Individual
Pendant Function Lock-Out
optional optional
Dimensions and Weight
Length (overall) 86-1/4” (2191 mm) 86-1/4” (2191 mm)
Length - Between head & foot end 83-3/4" (2127 mm) 83-3/4" (2127 mm)
Length - Mattress Platform 80" (2032 mm) 80" (2032 mm)
Width (with Assist Rails) 40" (1016 mm) 40" (1016 mm)
Width - Mattress Platform 35-1/2" (902 mm) 35-1/2" (902 mm)
Weight (pounds) 190 lb. (86 kg) 190 lb. (86 kg)
Load Capacity - Safe Working Load 500 lb. (228 kg) 500 lb. (228 kg)
