Bed Function
1-150-068-A CS Bed Manual.doc © Carroll Healthcare Inc. Page 24 of 35
CS Bed Mobilization and Stabilization
Unintended bed movement may occur if the floor lock or bed casters are left unlocked.
Unintended bed movement may cause property DAMAGE or resident INJURY. Never leave
the bed unattended while the floor lock is disengaged.
Floor Lock Operation
Depress the floor lock pedal bar with
your foot.
The plunger provides a visible clue that
the floor lock is engaged
Floor lock engaged will prevent the bed
from moving .
Depress the floor lock pedal bar again
from the locked position.
The visible green plunger indicates that
the floor lock is NOT engaged.
Floor lock disengaged will allow the
bed to move in all directions.
Moving the bed while the floor lock is engaged may DAMAGE the bed.
Do not move the bed unless the floor lock is disengaged (unlocked).
Bed Steer Mechanism
Steer mechanism is on either side of the
head end of the bed.
With the locking wheel tab facing
outward, flip the steer mechanism.
When engaged, the bed will steer
easily.
