SECTION 4—PACKAGING, HANDLING, AND SET-UP
IVC
™
Bed Series 32 Part No 1114836
Installing/Removing the Pendant
NOTE: For this procedure, refer to FIGURE 4.14.
For Canadian Customers who need to
disable operation of electric beds: These
Models have pendants that can be
removed and stored in a secure place.
1. To disable operation of the electric bed,
unscrew the union nut on the standard
pendant cable that attaches to the
extension cable.
2. Unplug the standard pendant cable
from the extension cable.
FIGURE 4.14 Installing/Removing the
Pendant
Storing the Beds
WARNING
DO NOT place other objects on top of the cartons.
If bed is not being assembled immediately, retain the cartons and packaging for storage
until ready for assembly.
Store the Invacare homecare bed in a dry area.
Standard
Pendant Cable
Bed Down
Button
Bed Up
Button
Extension Cable
Union Nut
To Next Page
