Invacare pegasus pro - Operating Console (LCD Version)

Components
(2)(3)(4)(5)(6)(7)(8)
Batterycapacity
<50%
<35%
<25%
<20%
3.3Operatingconsole(LCDversion)
Arrangement
A
Statusdisplay
B
Switchingon/offcurvecontrol(reductionofspeed
whendrivinginacurve)
C
Hazardlights
D
Horn
E
Left-handdirectionindicator(switchesitselfoff
automaticallyafter30seconds)
F
Speedcontroldial
G
Right-handdirectionindicator(switchesitselfoff
automaticallyafter30seconds)
H
Lighting
I
Lowspeedmode
J
Setting
K
Drivelever
Statusdisplay
A
Speedindication
B
Faultindication
C
Curvecontrolindication
D
Maintenanceindication
1
E
Headlightindication
F
Leftturnindication
