Invacare®PegasusSeries
Initialsetupshouldalwaysbedonebyahealthcare
professional.Adjustmentbytheuserisonly
recommendedaftertheyhavebeengiven
appropriateguidancebythehealthcareprofessional.
Notethattheremaybesectionsinthisusermanual,
whicharenotrelevanttoyourproduct,sincethis
manualappliestoallexistingmodules(onthedate
ofprinting).
4.2Movingtheseatpositionforwardsor
backwards
Thedisengagingleverforadjustingtheseatislocatedfront
rightbelowtheseat.
1.PulltheleverAtodisengagetheseat.
2.Slidetheseatforwardsorbackwardsintotherequired
position.
3.Releasethelevertolocktheseatintotherequired
position.
4.3Adjustingthearmrestwidth
WARNING!
Seriousinjury
Ifoneofthearmrestsisadjustedtoawidth
whichexceedsthepermissiblevaluethearmrest
fallsoutofitsbracketswhichcouldleadto
seriousinjury.
–Thewidthadjustmentisttedwithsmall
stickerswithmarkingsandtheword“STOP”.
Thearmrestmustneverbepulledoutfurther
thenthepointatwhichtheword“STOP”is
completelylegible.
–Alwaystightenthexingscrewsproperlyonce
adjustmentshavebeencompleted.
Theknobsforreleasingthearmrestsarelocatedunderthe
seat.
