Invacare®PegasusSeries
11Troubleshooting
11.1Diagnosisandfaultrepair
Theelectronicsystemoffersdiagnosticinformation
tosupportthetechnicianduringtherecognitionand
recticationoffaultsonthescooter .
Theelectronicsystemreactsdifferentlydependingonthe
seriousnessofthefaultanditseffectonusersafety.Itcan,
forexample:
•Displaytheerrorcodeasawarningandallowboth
drivingandnormaloperationtocontinue.
•Displaytheerrorcode,stopthescooterandprevent
furthertraveluntiltheelectronicsystemhasbeen
switchedoffandswitchedonagain.
•Displaytheerrorcode,stopthescooterandnotpermit
furthertraveluntilthefaulthasbeenrectied.
Youcannddetaileddescriptionsofindividualerrorcodes,
includingpossiblecausesandfaultrepair,in11.1.2Error
codesanddiagnosticcodes,page57.
11.1.1Errordiagnosis
Ifthescootershowsafailure,usethefollowingguideto
locatethefault.
Beforemakinganydiagnosis,ensurethatthescooter
hasbeenswitchedonatthekeyswitch.
Ifthestatusdisplay/LCDdisplayisOFF:
•CheckwhetherthekeyswitchisSWITCHEDON.
•Checkwhetherallcablesarecorrectlyconnected.
LEDconsole
Ifthereisafault,thestatusdisplay(1)ashesseveraltimes,
pauses,thenashesagain.Thetypeoffaultisdisplayedby
thenumberofasheswhicharealsoknownasthe"ash
code".Countthenumberofashesandproceedto11.1.2
Errorcodesanddiagnosticcodes,page57.
LCDconsole
Ifthereisafault,thefaultindicationsymbolA,thenumber
BandthenameofthefaultCareshownintheLCDdisplay.
Referto11.1.2Errorcodesanddiagnosticcodes,page57.
561638629-A
