INVENTOR Cool 8000btu User Manual

Ambient temperature
Ambient Temperature range of the unit is 16°C - 30 °C.
Cool Mode
1 In the COOLING Mode the appliance must be placed close to a window or opening so
that the warm exhaust air can be ducted outside through the window.
2 Press ON / OFF to turn on unit, press MODE to select cool mode, which is indicated
with the “ ” light on and unit runs in cooling mode.
3 Press the + or – button on the unit or the remote to set the temperature between 16°C -
30 °C.
4 Press SPEED button on the remote to select proper fan speed (High/Medium/Low).
Compressor delay protection
Compressor switches OFF on changing modes before switching ON. Wait approximately
3 minutes and for compressor to restart. This prevents overheating of the compressor and
possible circuit breaker tripping. The fan will continue to run during this time.
Note
When in drying mode, indoor fan motor runs in low speed, compressor runs continuously,
set temperature will not be displayed and is not adjustable. Exhaust hose does not need.
FAN
Press “ON/OFF” to turn on unit and select FAN by SPEED, indoor fan motor can run in
3 speeds of High, Medium and low, set temperature will not be displayed and is not
adjustable, High, Medium or low symbol will be displayed in display window according
to speed of indoor fan.
8

INVENTOR Cool 8000btu Specifications

General

Model no.	Cool 8000
Refrigerant	R410A (460g)
Timer	1～24 hours
Cooling capacity	8000 BTU/hr 2345watts
Air volume (H/M/L)	3 350X300X250 m /h
Humidity removal capacity	0.75L/hour
Fan speed	3
Power/Ampere consumption for cooling	1130 W/ 4.6A
Power supply	220-240V~. 50Hz
Compressor	rotary
Exhaust pipe	Ø 142x1500mm
Noise Level	56/54/52 dB(A)
Working temperature	o Cooling: 16 ~ 30 C

Weight and Dimensions

Net Weight	24 kgs
Gross Weight	28 kgs
Net Dimension	300x800x355 mm (WxHxD)
Gross Dimension	355x850x565 mm (WxHxD)
