INVENTOR Cool 8000btu User Manual

ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE
Installation of the Exhaust Hose and Adapter
1. Position the Air conditioner to its required location. See “Location Requirements.”
2. Insert one end of the flexible exhaust hose into the exhaust adapter.
3. Twist clockwise to lock hose into place.
4. Insert the other end of the flexible exhaust hose into the window exhaust adapter.
5. Twist clockwise to lock hose into place.
A
B
C
● Length of the exhaust pipe should be ranging from 500mm-1500mm. It is recommended
to use it with shortest length.
● When installing the exhaust pipe, it should be as straight as possible. Don't extend the
pipe or connect it with other exhaust pipe as it may cause damage to the unit.
Correct installation is as shown in figure (When installing it on wall, position of the hole
should be about 40cm - 130cm from the floor).
14

INVENTOR Cool 8000btu Specifications

General

Model no.	Cool 8000
Refrigerant	R410A (460g)
Timer	1～24 hours
Cooling capacity	8000 BTU/hr 2345watts
Air volume (H/M/L)	3 350X300X250 m /h
Humidity removal capacity	0.75L/hour
Fan speed	3
Power/Ampere consumption for cooling	1130 W/ 4.6A
Power supply	220-240V~. 50Hz
Compressor	rotary
Exhaust pipe	Ø 142x1500mm
Noise Level	56/54/52 dB(A)
Working temperature	o Cooling: 16 ~ 30 C

Weight and Dimensions

Net Weight	24 kgs
Gross Weight	28 kgs
Net Dimension	300x800x355 mm (WxHxD)
Gross Dimension	355x850x565 mm (WxHxD)
