Optidrive P2 Advanced User Guide Rev 2.00
Optidrive P2 Parameter Set Overview
Energy Consumption MWh Meter
Displays the amount of energy consumed by the drive in MWh.
This parameter contains 2 values. The first value, visible when entering the parameter, is the User Resettable MWh meter, which can
be reset by setting P6-23 = 1. The second value cannot be reset by the user, and indicates the energy consumed by the drive when
operating since the date of manufacture.
Software Version and Checksum
Displays the software version of the drive
Displays the type details of the drive
Displays the unique serial number of the drive.
Drive Lifetime Operating Time
Displays the total operating time of the drive. The first value shown is the number of hours. Pressing the Up key will display the
minutes and seconds.
Drive Run Time Since Last Trip (1)
Displays the total operating time of the drive since the last fault occurred. The first value shown is the number of hours. Pressing the
Up key will display the minutes and seconds.
Drive Run time Since Last Trip (2)
Displays the total operating time of the drive since the last fault occurred. The first value shown is the number of hours. Pressing the
Up key will display the minutes and seconds.
Drive Run Time Since Last Disable
Displays the total operating time of the drive since the last Run command was received. The first value shown is the number of hours.
Pressing the Up key will display the minutes and seconds.
Drive Internal Cooling Fan Total Operating Time
Displays the total operating time of the Optidrive internal cooling fans. The first value shown is the number of hours. Pressing the Up
key will display the minutes and seconds. This is used for scheduled maintenance information
DC Bus Voltage Log (256ms)
DC Bus Voltage Ripple Log (20ms)
Heatsink Temperature Log (30s)
Ambient Temperature Log (30s)
Motor Current Log (256ms)
The above parameters are used to store the history of various measured levels within the drive at various regular time intervals prior
to a trip. The values are frozen when a fault occurs and can be used for diagnostic purposes – see section for further information.
Critical Fault Counter – Over Current
Critical fault counter – Over Voltage
Critical fault counter – Under Voltage
Critical fault counter – Over Temperature
Critical fault counter – Brake Transistor Over Current
Critical fault counter – Ambient Over Temperature
These parameters contain a record of how many times certain critical faults have occurred during a drives operating lifetime. This
provides useful diagnostic data
I/O Processor Error Count
Displays the relevant internal error count for the drive processors, sueful for diagnostics.
Modbus RTU Communication Error Counter
This parameter is incremented every time an error occurs on the Modbus RTU communication link. This information can be used for
diagnostic purposes.
CAN Open Communication Error Counter
This parameter is incremented every time an error occurs on the CAN Open communication link. This information can be used for
diagnostic purposes.
Displays the incoming PDI processor data when a fieldbus interface is connected and operating that supports process data
interchange, useful for fieldbus diagnostics and trouble shooting.
Displays the outgoing PDO processor data when a fieldbus interface is connected and operating that supports process data
interchange, useful for fieldbus diagnostics and trouble shooting.
Current Phase U Offset and Ref
Index 1 : Reference
Index 2 : Sampled Value
Current Phase V Offset and Ref
Index 1 : Reference
Index 2 : Sampled Value
Brake Max On Time and Duty Cycle
Index 1 : Max On Time
Index 2 : Duty
