Optidrive P2 Advanced User Guide Rev 2.00
28
www.invertekdrives.com
Optidrive P2 Parameter Set Overview
1
Par
Description
Units
P0-57
Ud / uq
-
Index 1 : Ud
Index 2 : Uq
P0-58
Encoder Feedback Speed Value
Hz / Rpm
P0-59
Frequency Input Reference
Displays the speed setpoint when a frequency input is used for the speed reference.
P0-60
Calculated Slip Speed Value (V/F Mode Only)
-
When slip compensation is enabled using P1-10, the calculated motor slip is displayed here. The raw value is displayed from internal
measurement, and does not directly represent Hz or Rpm.
P0-61
Relay Control Speed Hysteresis Value
Hz / Rpm
Displays the speed hysteresis value in use for output relay settings that use hysteresis, defined by P6-04.
P0-62
Droop Speed
-
Displays the droop speed when droop control is used. The raw value is displayed from internal measurement, and does not directly
represent Hz or Rpm.
P0-63
Post Ramp Speed Reference
Hz / Rpm
Displays the speed reference after all ramps and limits are applied.
P0-64
Internal Effective Switching Frequency
kHz
Shows the effective switching frequency presently active.
P0-65
Drive Life Time
HH:MM:SS
Displays the total time for which the drive has been powered on. The value is not resettable.
P0-66
Function Block Program ID
-
Displays the ID of any internally loaded Function Block Program.
P0-67
Fieldbus Torque Reference
-
Displays the value of the torque reference received via a connected fieldbus interface if one is present. The value shown is the internal
value, and does not directly represent Nm or %.
P0-68
User Ramp Value
s
Displays the “User Ramp Time” value, which may be set via the internal Function Block Program.
P0-69
I2C Error Count
P0-70
Option Module Type
Displays the type of option module fitted in the drive option slot. The displayed values are
 : Incremental Encoder Interface
 : Extended I/O or Cascade Module
 : Fieldbus Interface
 : No Module Fitted
 : Unkown or onrecognised Module
P0-71
Fieldbus Interface Type
Displays the type of option module, if fitted in the drive option slot. The displayed values are
. : No Filedbus Module
 : Profibus Module fitted
 : DeviceNet Module fitted
 : Ethernet IP Module fitted
P0-72
Ambient Temperature
°C
Internal Value
P0-73
24 Hour Timer
HH:MM
Internal Value
P0-74
L1 – L2 Input Voltage
Volts
Displays the supply voltage measured between L1 and L2 terminals, for indication to the user
P0-75
L2 – L3 Input Voltage
Volts
Displays the supply voltage measured between L2 and L3 terminals, for indication to the user
P0-76
L3 – L1 Input Voltage
Volts
Displays the supply voltage measured between L3 and L1 terminals, for indication to the user
P0-77
Test Parameter
-
Internal Value
P0-78
Test Parameter
-
Internal Value
P0-79
Motor Control & DSP Version
-
Internal Value
P0-80
User Defined Internal Parameter
-
Internal Value. Refer to section 1.6 for further information.
