Parameter Access Tables
www.invertekdrives.com
Optidrive P2 Advanced User Guide Revision 2.00
Parameter
Number
R/W
Modbus
RTU
Register
Number
CAN
Open
Index
CAN
Open
Sub
Index
Profibus
DP
DeviceNet
EtherNet
IP
EtherCAT
Modbus
TCP
Profinet
IO
Scaling
Type
P9-09
R/W
909
238Dh
0h
3, 143
A2h, 909, X
A2h, 909, X
238Dh
1436
0, 0, 1, 038Dh
Terminal Control
Override Source
3 : Digital Input 3
4 : Digital Input 4
5 : Digital Input 5
6 : Digital Input 6
7 : Digital Input 7
8 : Digital Input 8
9 : Analog Output 1
10 : Analog Output 2
11 : Digital Output 1
12 : Digital Output 2
13 : Digital Output 3
14 Digital Output 4
15 : Digital Output 5
16 : ON
17 : User Register 1
18 : User Register 2
19 : User Register 3
20 : User Register 4
21 : User Register 5
22 : User Register 6
23 : User Register 7
24 : User Register 8
25 : User Register 9
U16
P9-10
R/W
910
238Eh
0h
3, 144
A2h, 910, X
A2h, 910, X
238Eh
1437
0, 0, 1, 038Eh
Speed Source 1
0 : Analog Input 1
1 : Analog Input 2
2 : Preset Speed
3 : Keypad Speed
4 : User PID Speed
5 : Master Speed
6 : Fieldbus Speed
7 : User Speed
8 : Frequency Input
9 : Preset Speed 1
10 : Preset Speed 2
11 : Preset Speed 3
12 : Preset Speed 4
13 : Preset Speed 5
14 : Preset Speed 6
15 : Preset Speed 7
16 : Preset Speed 8
U16
P9-11
R/W
911
238Fh
0h
3, 145
A2h, 911, X
A2h, 911, X
238Fh
1438
0, 0, 1, 038Fh
Speed Source 2
U16
P9-12
R/W
912
2390h
0h
3, 146
A2h, 912, X
A2h, 912, X
2390h
1439
0, 0, 1, 0390h
Speed Source 3
U16
P9-13
R/W
913
2391h
0h
3, 147
A2h, 913, X
A2h, 913, X
2391h
1440
0, 0, 1, 0391h
Speed Source 4
U16
P9-14
R/W
914
2392h
0h
3, 148
A2h, 914, X
A2h, 914, X
2392h
1441
0, 0, 1, 0392h
Speed Source 5
U16
P9-15
R/W
915
2393h
0h
3, 149
A2h, 915, X
A2h, 915, X
2393h
1442
0, 0, 1, 0393h
Speed Source 6
U16
P9-16
R/W
916
2394h
0h
3, 150
A2h, 916, X
A2h, 916, X
2394h
1443
0, 0, 1, 0394h
Speed Source 7
U16
P9-17
R/W
917
2395h
0h
3, 151
A2h, 917, X
A2h, 917, X
2395h
1444
0, 0, 1, 0395h
Speed Source 8
U16
P9-18
R/W
918
2396h
0h
3, 152
A2h, 918, X
A2h, 918, X
2396h
1445
0, 0, 1, 0396h
Speed Source Select
Input Bit 0
0 : Safety Input
1 : Digital Input 1
2 : Digital Input 2
3 : Digital Input 3
4 : Digital Input 4
5 : Digital Input 5
6 : Digital Input 6
7 : Digital Input 7
8 : Digital Input 8
9 : Analog Output 1
10 : Analog Output 2
11 : Digital Output 1
12 : Digital Output 2
13 : Digital Output 3
14 Digital Output 4
15 : Digital Output 5
U16
P9-19
R/W
919
2397h
0h
3, 153
A2h, 919, X
A2h, 919, X
2397h
1446
0, 0, 1, 0397h
Speed Source Select
Input Bit 1
U16
P9-20
R/W
920
2398h
0h
3, 154
A2h, 920, X
A2h, 920, X
2398h
1447
0, 0, 1, 0398h
Speed Source Select
Input Bit 2
U16
P9-21
R/W
921
2399h
0h
3, 155
A2h, 921, X
A2h, 921, X
2399h
1448
0, 0, 1, 0399h
Preset Speed Select
Bit 0
U16
P9-22
R/W
922
239Ah
0h
3, 156
A2h, 922, X
A2h, 922, X
239Ah
1449
0, 0, 1, 039Ah
Preset Speed Select
Bit 1
U16
P9-23
R/W
923
239Bh
0h
3, 157
A2h, 923, X
A2h, 923, X
239Bh
1450
0, 0, 1, 039Bh
Preset Speed Select
Bit 2
U16
P9-24
R/W
924
239Ch
0h
3, 158
A2h, 924, X
A2h, 924, X
239Ch
1451
0, 0, 1, 039Ch
Acceleration Ramp
Select Bit 0
U16
P9-25
R/W
925
239Dh
0h
3, 159
A2h, 925, X
A2h, 925, X
239Dh
1452
0, 0, 1, 039Dh
Acceleration Ramp
Select Bit 1
U16
