Parameter Access Tables
www.invertekdrives.com
Optidrive P2 Advanced User Guide Revision 2.00
4.7.9. Parameter Group 9 ADI’s
Parameter
Number
R/W
Modbus
RTU
Register
Number
CAN
Open
Index
CAN
Open
Sub
Index
Profibus
DP
DeviceNet
EtherNet
IP
EtherCAT
Modbus
TCP
Profinet
IO
Scaling
Type
P9-01
R/W
901
2385h
0h
3, 135
A2h, 901, X
A2h, 901, X
2385h
1428
0, 0, 1, 0385h
Enable Source
0 : Safety Input
1 : Digital Input 1
2 : Digital Input 2
3 : Digital Input 3
4 : Digital Input 4
5 : Digital Input 5
6 : Digital Input 6
7 : Digital Input 7
8 : Digital Input 8
U16
P9-02
R/W
902
2386h
0h
3, 136
A2h, 902, X
A2h, 902, X
2386h
1429
0, 0, 1, 0386h
Fast Stop Source
0 : Safety Input
1 : Digital Input 1
2 : Digital Input 2
3 : Digital Input 3
4 : Digital Input 4
5 : Digital Input 5
6 : Digital Input 6
7 : Digital Input 7
8 : Digital Input 8
9 : Analog Output 1
10 : Analog Output 2
11 : Digital Output 1
12 : Digital Output 2
13 : Digital Output 3
14 Digital Output 4
15 : Digital Output 5
16 : ON
17 : User Register 1
18 : User Register 2
19 : User Register 3
20 : User Register 4
21 : User Register 5
22 : User Register 6
23 : User Register 7
24 : User Register 8
25 : User Register 9
U16
P9-03
R/W
903
2387h
0h
3, 137
A2h, 903, X
A2h, 903, X
2387h
1430
0, 0, 1, 0387h
Run Forward Source
U16
P9-04
R/W
904
2388h
0h
3, 138
A2h, 904, X
A2h, 904, X
2388h
1431
0, 0, 1, 0388h
Run Reverse Source
U16
P9-05
R/W
905
2389h
0h
3, 139
A2h, 905, X
A2h, 905, X
2389h
1432
0, 0, 1, 0389h
Latch Enable
0 : Disabled
1 : Enabled
U16
P9-06
R/W
906
238Ah
0h
3, 140
A2h, 906, X
A2h, 906, X
238Ah
1433
0, 0, 1, 038Ah
Reverse Source
0 : Safety Input
1 : Digital Input 1
2 : Digital Input 2
U16
P9-07
R/W
907
238Bh
0h
3, 141
A2h, 907, X
A2h, 907, X
238Bh
1434
0, 0, 1, 038Bh
Reset Source
U16
P9-08
R/W
908
238Ch
0h
3, 142
A2h, 908, X
A2h, 908, X
238Ch
1435
0, 0, 1, 038Ch
External Trip Source
U16
