Parameter Access Tables
www.invertekdrives.com
Optidrive P2 Advanced User Guide Revision 2.00
4.7.8. Group 8 : Application Specific Parameters - Level 3
Parameter
Number
R/W
Modbus
RTU
Register
Number
CAN
Open
Index
CAN
Open
Sub
Index
Profibus
DP
DeviceNet
EtherNet
IP
EtherCAT
Modbus
TCP
Profinet
IO
Parameter Name
Setting Range
Scaling
Type
P8-01
R/W
801
2321h
0h
3, 35
A2h, 801, X
A2h, 801, X
2321h
1328
0, 0, 1, 0321h
Accel Ramp 2
0 to 60000
S2…S3 1 = 0.01s
S4…S7 1 = 0.1s
U16
P8-02
R/W
802
2322h
0h
3, 36
A2h, 802, X
A2h, 802, X
2322h
1329
0, 0, 1, 0322h
Speed boundary –
Accel ramp 1  2
0 to 30000 (Limited by P1-01 Setting)
3000 = 50.0Hz
U16
P8-03
R/W
803
2323h
0h
3, 37
A2h, 803, X
A2h, 803, X
2323h
1330
0, 0, 1, 0323h
Accel Ramp 3
0 to 60000
S2…S3 1 = 0.01s
S4…S7 1 = 0.1s
U16
P8-04
R/W
804
2324h
0h
3, 38
A2h, 804, X
A2h, 804, X
2324h
1331
0, 0, 1, 0324h
Speed boundary –
Accel ramp 2  3
0 to 30000 (Limited by P1-01 Setting)
3000 = 50.0Hz
U16
P8-05
R/W
805
2325h
0h
3, 39
A2h, 805, X
A2h, 805, X
2325h
1332
0, 0, 1, 0325h
Accel Ramp 4
0 to 60000
S2…S3 1 = 0.01s
S4…S7 1 = 0.1s
U16
P8-06
R/W
806
2326h
0h
3, 40
A2h, 806, X
A2h, 806, X
2326h
1333
0, 0, 1, 0326h
Speed boundary –
Accel ramp 3  4
0 to 30000 (Limited by P1-01 Setting)
3000 = 50.0Hz
U16
P8-07
R/W
807
2327h
0h
3, 41
A2h, 807, X
A2h, 807, X
2327h
1334
0, 0, 1, 0327h
Decel Ramp 4
0 to 60000
S2…S3 1 = 0.01s
S4…S7 1 = 0.1s
U16
P8-08
R/W
808
2328h
0h
3, 42
A2h, 808, X
A2h, 808, X
2328h
1335
0, 0, 1, 0328h
Speed boundary –
Accel ramp 4  3
0 to 30000 (Limited by P1-01 Setting)
3000 = 50.0Hz
U16
P8-09
R/W
809
2329h
0h
3, 43
A2h, 809, X
A2h, 809, X
2329h
1336
0, 0, 1, 0329h
Decel Ramp 3
0 to 60000
S2…S3 1 = 0.01s
S4…S7 1 = 0.1s
U16
P8-10
R/W
810
232Ah
0h
3, 44
A2h, 810, X
A2h, 810, X
232Ah
1337
0, 0, 1, 032Ah
Speed boundary –
Accel ramp 3  2
0 to 30000 (Limited by P1-01 Setting)
3000 = 50.0Hz
U16
P8-11
R/W
811
232Bh
0h
3, 45
A2h, 811, X
A2h, 811, X
232Bh
1338
0, 0, 1, 032Bh
Decel Ramp 2
0 to 60000
S2…S3 1 = 0.01s
S4…S7 1 = 0.1s
U16
P8-12
R/W
812
232Ch
0h
3, 46
A2h, 812, X
A2h, 812, X
232Ch
1339
0, 0, 1, 032Ch
Speed boundary –
Accel ramp 2  1
0 to 30000 (Limited by P1-01 Setting)
3000 = 50.0Hz
U16
P8-13
R/W
813
232Dh
0h
3, 47
A2h, 813, X
A2h, 813, X
232Dh
1340
0, 0, 1, 032Dh
Ramp select by Preset Speed
0: Disabled
1: Enable
WORD
