INVT GD170-045-4-PV User Manual

Goodrive170-PV Series Solar Pump Inverter Function parameter list
-25-
Function
code
Name
Description
Default
Modify
inverter. If the power of
the motor is greatly
different from that of the
standard motor
configuration, the control
performance of the
inverter degrades
significantly.
Note: Resetting the
rated power of the motor
(P02.01) can initialize the
parameters P02.02–
P02.10.
P02.06
Stator
resistance of
AM
0.001–
65.535Ω
After motor parameter
autotuning is properly
performed, the values of
P02.06–P02.10 are
automatically updated.
These parameters are
the benchmark
parameters for
high-performance vector
control, directly affecting
the control performance.
Note: Do not modify
these parameters unless
it is necessary.
Model
depended
○
P02.07
Rotor
resistance of
AM
0.001–
65.535Ω
Model
depended
○
P02.08
Leakage
inductance of
AM
0.1–
6553.5mH
Model
depended
○
P02.09
Mutual
inductance of
AM
0.1–
6553.5mH
Model
depended
○
P02.10
No-load current
of AM
0.1–6553.5A
Model
depended
○
P02.15
Rated power of
SM
0.1–
3000.0kW
Used to set SM
parameters.
To ensure the control
performance, set
P02.15–P02.19 correctly
according to the
information on the
nameplate of the AM.
The inverter provides the
parameter autotuning
Model
depended
◎
P02.16
Rated
frequency of
SM
0.01Hz–
P00.03 (Max.
output
frequency)
50.00Hz
◎
P02.17
Number of pole
pairs of SM
1–128
2
◎
P02.18
Rated voltage
of SM
0–1200V
Model
depended
◎
