INVT GD170-045-4-PV User Manual

Goodrive170-PV Series Solar Pump Inverter Function parameter list
-45-
Function
code
Name
Description
Default
Modify
frequency
input
If P15.33 is set to 0, it is invalid.
For inverter models without boost modules,
the switching voltage is determined by the
external voltage detection circuit.
For inverter models with boost modules,
the switching voltage is 70V.
P15.34
Threshold
for
switching
to PV input
P15.33–400.0V
If PV voltage is greater than the threshold,
the system can switch to PV input through
relay output with the weak-light wake-up
delay (P15.24). To avoid frequent
switching, P15.34 shall be greater than
P15.33. When P15.34 is set to 0.0, it is
invalid.
The default value depends on model.
100.0V
○
P15.35
Rated
pump flow
The pump flow is Q
N
when the pump runs
at the rated frequency and lift. Unit: cubic
meter/hour
0.0
○
P15.36
Rated
pump lift
The pump lift is H
N
when the pump runs at
the rated frequency and flow. Unit: meter
0.0
○
P15.37
Voltage
setting at
PV
undervolta
ge point
When the PV voltage is less than the value
of this parameter, the system reports the
PV undervoltage fault.
The factory value depends on the model.
Model
PV undervoltage
point
-4
240V
Any model
with the boost
module
70V
Setting range: 0.0–400.0
70.0
○
P15.39
Product
model
This function code is provided for users to
change models. For example, if the user
wants to use model -4 (default after factory
delivery) as model -2, P15.39 shall be set
to 2.
0
◎
