INVT GD170-045-4-PV User Manual

Goodrive170-PV Series Solar Pump Inverter Function parameter list
-47-
Function
code
Name
Description
Default
Modify
P15.48
Flow point
3 of PQ
curve
It indicates the flow point corresponding to
the pump flow at the 3
rd
point of the PQ
curve.
0.0
◎
P15.49
Flow point
4 of PQ
curve
It indicates the flow point corresponding to
the pump flow at the 4
th
point of the PQ
curve.
0.0
◎
P15.50
Flow point
5 of PQ
curve
It indicates the flow point corresponding to
the pump flow at the 5
th
point of the PQ
curve.
0.0
◎
P15.51
Efficiency
of pump
This function code indicates the overall
efficiency of the pump.
80%
○
P17 group Status viewing
Function
code
Name
Description
Default
Modify
P17.38
Current of
the main
winding
It is current of the main winding when
applying capacitance-removing to control
the single-phase motor.
0.00–100.00A
0.0A
●
P17.39
Current of
the
secondary
winding
It is current of the secondary winding when
applying capacitance-removing to control
the single-phase motor.
0.00–100.00A
0.0A
●
P18 group Status viewing functions special for solar inverters
Function
code
Name
Description
Default
Modify
P18.00
PV
reference
voltage
MPPT is performed at the inverter side.
The value is given by the inverter side.
●
P18.01
Actual PV
voltage
It is transferred from the boost module or
equal to bus voltage.
●
P18.02
MPPT min.
reference
voltage
display
The value displays the mini. voltage
reference during max. power tracking. It
equals to the solar cell panel open-circuit
voltage multiplied P15.26.
●
