Goodrive170-PV Series Solar Pump Inverter Function parameter list
-49-
P19 group Functions for voltage boost (inverter module communicates with boost
module through RS485 communication)
Output
current
upper limit
of boost
voltage
loop PI
Output upper limit of mppt voltage loop PI,
upper limit of the boost current loop
reference current.
P19.05–15.0A
This function code is used to set the
reference voltage of bus voltage at PV
input when the system is configured with
the boost module. By default, the factory
value for 220V models is 350V and the
factory value for 380V models is 570V.
Setting range: 300.0V–600.0V
If the difference between the bus reference
voltage and actual bus voltage is greater
than 20V, the boost voltage loop uses PI
parameters of this group. Otherwise, the
boost voltage loop uses PI parameters of
the first group.
Setting range: 0.000–65.535
