INVT Goodrive200A Series User Manual

GD200A series VFD Function parameters
-50-
Function
code
Name
Description
Default
value
Modify
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: MODBUS communication setting torque
8–10: Reserved
Note: For setting modes 2–5, 100% corresponds
to three times of the rated current of the motor.
P03.12
Keypad setting
torque
Setting range: -300.0%–300.0% (rated current of
the motor)
50.0%
○
P03.13
Torque
reference filter
time
0.000–10.000s
0.010s
○
P03.14
Upper
frequency of
forward rotation
in vector
control
0: Keypad (P03.16 sets P03.14, P03.17 sets
P03.15)
1: AI1 (implemented through the analog
potentiometer on the keypad for the 0150G/018P
and lower models; not available for the
018G/022P and higher models.)
2: AI2
3: AI3
4: Pulse frequency HDI setting upper-limit
frequency
5: Multi-step setting upper-limit frequency
6: MODBUS communication setting upper-limit
frequency
Note: Setting method 1–6, 100% corresponds to
the maximum frequency
0
○
P03.15
Upper
frequency of
reverse rotation
in vector
control
0
○
P03.16
Keypad setting
for upper
frequency of
forward rotation
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz–P00.03 (the max. output
frequency)
50.00
Hz
○
P03.17
Keypad setting
for upper
frequency of
reverse rotation
50.00
Hz
○
P03.18
Upper electro
motion torque
source
This function code is used to select the electro
motion and braking torque upper-limit setting
source selection.
0
○
