INVT Goodrive200A Series User Manual

GD200A series VFD Function parameters
-69-
Function
code
Name
Description
Default
value
Modify
commands
1: Keypad control←→terminals control
2: Keypad control←→communication control
3: Terminals control←→communication control
P07.04
STOP/RST
stop function
STOP/RST is valid for stop function. STOP/RST
is valid in any state for the fault reset.
0: Only valid for the keypad control
1: Both valid for keypad and terminals control
2: Both valid for keypad and communication
control
3: Valid for all control modes
0
○
P07.05
Parameters
state 1
0x0000–0xFFFF
BIT0: running frequency (Hz on)
BIT1: set frequency (Hz flickering)
BIT2: bus voltage (Hz on)
BIT3: output voltage (V on)
BIT4: output current (A on)
BIT5: running rotation speed (rpm on)
BIT6: output power (% on)
BIT7: output torque (% on)
BIT8: PID reference (% flickering)
BIT9: PID feedback value (% on)
BIT10: input terminals state
BIT11: output terminals state
BIT12: torque set value (% on)
BIT13: pulse counter value
BIT14: length value
BIT15: PLC and the current stage in multi-step
speed
0x03FF
○
P07.06
Parameters
state 2
0x0000–0xFFFF
BIT0: AI1 (V on) (implemented through the analog
potentiometer on the keypad for the 0150G/018P
and lower models; not available for the
018G/022P and higher models.)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: HDI frequency
BIT4: motor overload percentage (% on)
BIT5: the VFD overload percentage (% on)
BIT6: ramp frequency given value (Hz on)
0x0000
○
