INVT Goodrive200A Series User Manual

GD200A series VFD Function parameters
-71-
Function
code
Name
Description
Default
value
Modify
P07.15
High bit of
power
consumption
Display the power used by the VFD.
The power consumption of the VFD
=P07.15*1000+P07.16
Setting range of P07.15: 0–65535 kWh (*1000)
Setting range of P07.16: 0.0–999.9 kWh
/
●
P07.16
Low bit of
power
consumption
/
●
P07.17
VFD type
0: G type
1: P type
/
●
P07.18
Rated power of
the VFD
0.4–3000.0kW
/
●
P07.19
Rated voltage
of the VFD
50–1200V
/
●
P07.20
Rated current
of the VFD
0.1–6000.0A
/
●
P07.21
Factory bar
code 1
0x0000–0xFFFF
/
●
P07.22
Factory bar
code 2
0x0000–0xFFFF
/
●
P07.23
Factory bar
code 3
0x0000–0xFFFF
/
●
P07.24
Factory bar
code 4
0x0000–0xFFFF
/
●
P07.25
Factory bar
code 5
0x0000–0xFFFF
/
●
P07.26
Factory bar
code 6
0x0000–0xFFFF
/
●
P07.27
Type of present
fault
0: No fault
1: IGBT U phase protection (OUt1)
2: IGBT V phase protection (OUt2)
3: IGBT W phase protection (OUt3)
4: OC1
5: OC2
6: OC3
7: OV1
8: OV2
9: OV3
10: UV
11: Motor overload (OL1)
12: The VFD overload (OL2)
/
●
P07.28
Type of the last
fault
/
●
P07.29
Type of the last
but one fault
/
●
P07.30
Type of the last
but two fault
/
●
P07.31
Type of the last
but three fault
/
●
P07.32
Type of the last
but four fault
/
●
