GD200A series VFD Function parameters
-87-
Setting range of P10.(2n,1<n<17): -100.0–100.0%
Setting range of P10.(2n+1,1<n<17):
0.0–6553.5s(min)
Simple PLC
0–7 step
ACC/DEC time
Below is the detailed instruction:
After the users select the corresponding
ACC/DEC time, the combined 16 binary bits will
change into decimal bit, and then set the
corresponding function codes.
Setting range: 0x0000–0xFFFF
Simple PLC
8–15 step
ACC/DEC time
0: Restart from the first step; stop during running
(cause by the stop command, fault or power loss),
run from the first step after restart.
1: Continue to run from the stop frequency; stop
during running (cause by stop command and
fault), the VFD will record the running time
automatically, enter into the step after restart and
keep the remaining running at the setting
frequency.
